| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-IBR1 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 45 work days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 300set/Year |
| Tile Type: | Galvanized/color-coated/cold-rolled/Aluminium Zinc Steel Sheet | Voltage: | 380V |
|---|---|---|---|
| Use: | Roofing | After-sales Service Provided: | Video Technical Support |
| Control System: | PLC(Touch Screen) | Name: | Automatic IBR Roof Sheet Profile Roll Forming Machine Manufacturer |
| Color: | Customers Requirement | Cutting Type: | Hydraulic Cutting |
| Forming Speed: | 8~15m/min | Weight: | 5T |
Metal Roof Sheet IBR Galvanized Steel Roll Forming Machine
Application of Metal Roof Sheet IBR Galvanized Steel Roll Forming Machine :
The IBR galvanized steel sheet produced by the metal roof IBR galvanized steel roll forming machine is an ideal material for roof and wall applications and interior design (such as ceilings, awnings).
Q1. What are the payment terms and delivery time of your metal roof sheet IBR galvanized steel roll forming machine?
A1: Pay a 30% deposit by wire transfer in advance. After and before you check the metal roof sheet IBR galvanized steel roll forming machine, 70% of the wire transfer balance will be used as a wire transfer delivery. Of course your payment terms are acceptable. After we receive the down payment, we will arrange production. About 30-45 days delivery.
Q2. Does your metal roof sheet IBR galvanized steel roll forming machine have after-sales support?
A2: Yes, we are happy to advise on our metal roof IBR galvanized steel roll forming machine, and we have skilled technicians all over the world.
Q3. Do you only sell standard machines?
A3: No, most of our machines are manufactured using top brand components according to customer specifications.
Technical parameters of metal roof IBR galvanized steel roll forming machine
| 1 | Suitable for | Galvanized Sheet |
| 2 | Forming rows | Trapezoid tile 15Rows |
| corrugated tile 15Rows | ||
| 3 | Feed width | 1200mm |
| 4 | Sheet Thickness | 0.3-0.8mm |
| 5 | Equipment shaft diameter | Φ70mm |
| 6 | monitor rate | 4KW |
| 7 | Rolling speed | 15m-60m/min |
| 8 | Machine weight | Around 4 tons |
| 9 | Pumping station motor | 4KW |
| 10 | Equipment rack | 300H steel |
| 11 | Equipment transmission | 0.6 inch chain drive |
| 12 | Cut-off system | Automatic computer fixed length |
| 13 | Roll material | 45 # steel forged parts |
| 14 | Shear blade heat treatment | HRC58 ° -60 ° |
| 15 | Cut off method | Hydraulic shear |
| 16 | Shear blade material | Cr12 |
| 17 | Tolerance | ±1mm |
