| Place of Origin: | Hebei China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-LG-22 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 40 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 80set/Year |
| Name: | Stud And Track Roll Forming Machine | Raw Material: | PPGI、GI |
|---|---|---|---|
| Certification: | New | Roller Material: | 45#steel |
| Feeding Width: | Provided | Machinery Test Report: | 8-20m/min |
| Warranty: | 18 Month | Weight: | 4-6T |
| Voltage: | 380V 50Hz 3Phases | After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service |
Fully automatic T-shaped keel forming machine for store ceiling
When decorating the ceiling in the store, we will choose to replace the installed and tightly connected quality T-shaped keel as the ceiling, because the store area is large and needs to hang a lot of fill lights, and the keel has better load-bearing capacity and oxidation resistance.
The T-shaped keel forming machine passes through the complete process of uncoiling, feeding, punching, pressing, shearing, and splicing to produce raw materials into T-shaped keels that meet your requirements.
The T-shaped keel machine produced by LIMING is for you to choose. The thickness of 1 mm thick galvanized steel strip is used as the raw material to ensure that the formed T-shaped keel has good load-bearing capacity and oxidation resistance. The alternative material is Gr12.
Model wheels (through various molding processes such as rough turning, heat treatment, fine turning, etc.) to ensure the accuracy of the size, the online punching machine makes your ceiling assembly easier and faster, and the die cutting ensures that your products can be directly installed without burrs.
Main parameters of T-shaped keel forming machine
| Machine name | T-shaped keel forming machine |
| Control System | NC-PLC Colored Touch Screen |
| Main Power | 5.5 kw |
| Pump Power | 4 kw |
| Power Supply | 380V, 3-Phase,50Hz |
| Forming Speed | 8-25m/min |
| Roll Station | 12stands |
| Roller Diameter | 52mm |
| Feeding Thickness | 0.3-1.0mm |
| Cutter Standard | Cr12 |
| Roller Standard | 45# Steel plating Chrome with heat treatment |
| Cr-Plating Size | 0.05mm |
| Overall Size | 15000×1000×1200mm |
| Total Weight | 4-6T |
