| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-Solar 4.8 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 45 work days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 450set/Year |
| Production Capacity:: | 10m-15/min | Material Of Blade:: | Cr12Mov,HRC58-62 |
|---|---|---|---|
| Dimension(L*W*H):: | 9500*1500*1200mm | Thickness:: | 0.3-1.2mm |
| Warranty:: | 2 Year | Voltage:: | 380V/220V |
| Weight:: | 9T | ||
| Highlight: | photovoltaic mount cnc roll forming machine,cnc custom roll forming machine,60m/min custom roll forming machine |
||
Building Materials Wholesale 60/min Photovoltaic Mount Forming Machine
Why can the photovoltaic support forming machine of Liming Pressing Machinery Co., Ltd. reach 60/min?
1. Liming Pressing Machinery Company has a design and R&D team for photovoltaic bracket forming machines. It has 16 years of design and manufacturing experience from raw materials to photovoltaic bracket profiles. This team has rich experience in operation, use and R&D and design. The photovoltaic stent forming machine has a reasonable structure, beautiful appearance and precise size.
2. The photovoltaic support molding machine adopts a reducer transmission method, which can ensure sufficient power of the photovoltaic support molding machine. At the same time, it is also equipped with a Gr12 mold wheel for the photovoltaic support molding machine, so that the roller kun has sufficient hardness and toughness to ensure Improve the stability of the photovoltaic support forming machine.
3. The photovoltaic support molding machine uses the roll punch developed by our company to further increase the punching speed, thereby changing the mode that the molding host needs to adjust the molding speed according to the punching speed, so as to achieve the goal of rapid production.
Technical parameters of Building Materials Wholesale 60/min Photovoltaic Mount Forming Machine
| Material | CR coil, GI coil |
| Size | 41*21mm; 41*41mm; 41*62mm; 41*82mm |
| Thickness | 2.0-2.5mm |
| Feeding width | 93-229mm |
| Strength | Q235-345Mpa |
| Speed | 10-15m/min |
| Size tolerance | 1mm |
| Cutting way | Non-stop cutting |
| Power | 22kw+15kw |
| Roller material | Cr12MoV |
| Cut blade material | Cr12MoV |
| Dimension | 25000*1600*1500mm (L*W*H) |
| Total weight | about 10tons |
