| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-lLGS1 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 30 work days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 450set/Year |
| Applicable Industries:: | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops | Work Pressure:: | 120 MPA---140 MPA |
|---|---|---|---|
| Raw Material: | Galvanized Steel Sheet | Warranty: | 2 Years |
| Voltage: | 380V/50HZ 3Phase | Thickness: | 0.7-1.3mm |
| Certification: | CE、BV、ISO | Speed: | 10-12/min |
| Feeding Widt1000h: | 89mm |
Intelligent light steel frame villa keel forming machine
The Intelligent light steel frame villa keel forming machine is a steel frame cold rolling mill that can realize continuous automatic production.
The Intelligent light steel frame villa keel forming machine includes hydraulic expansion uncoiler, straightening equipment, forming system, stamping equipment, cutting equipment, hydraulic station, electrical control system and purlin supporter.
The Intelligent light steel frame villa keel forming machine adopts PLC control and AC frequency conversion speed regulation technology to realize continuous automatic production.
The Intelligent light steel frame villa keel forming machine is energy-efficient and efficient. This is a steel structure production machine.
Technical parameters of Intelligent light steel frame villa keel forming machine
| Size | 3850*800*1100mm |
| Weight | 2500KGS |
| Main Servo Motor Power | 7.5KW |
| Hydraulic Power for Punching & Cutting | 7.5KW |
| Forming Steps | 7 steps roll forming+2 steps reshaping |
| Processing Speed | Typical Drywall Panel Frame 600-720m/h |
| Roll Forming Speed without punch:2700m/h | |
| Over All Production Capacity:3-4tons/8hours | |
| Voltage | 380V/50HZ/3PH |
| Flange Height | 38mm |
| Web Width | 89mm |
| Lip Width | 9mm |
| Tolerence Of Cutting & Punching | ±0.5mm |
| Tolerence Of Forming | 0.75mm |
| Forming Thickness | 0.7mm -1.2mm |
