| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-lLGS17 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 30 work days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 450set/Year |
| Rolling Thinckness:: | 0.6-1.2MM | After Warranty Service:: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service |
|---|---|---|---|
| Length Devitation:: | ±0.75mm | Voltage:: | 220V Or 380V |
| Producting Speed:: | 300-700m/h | Design System:: | Australia Vertex BD |
| Certification: | CE、BV、ISO | Weight:: | 3.5Tons |
| Dimension(L*W*H):: | 4500*500*1000mm | ||
| Highlight: | 3 Tons Light Gauge Steel Machine,220V Steel Villa Forming Machine,3 Tons Steel Villa Forming Machine |
||
Prefabricated Building Light Steel Frame Villa Keel Forming Machine
"Prefabricated building light steel frame villa keel forming machine" adopts vretex BD technology to realize the intelligent and highly automated production of equipment;
"Prefabricated building light steel frame villa keel forming machine" monitors the production process in real time and can clearly display the production process and progress.
"Prefabricated building light steel frame villa keel forming machine" reduces production machinery loss and equipment failure alarms.
"Prefabricated building light steel frame villa keel forming machine" is equipped with a luxurious version of the rotatable 17-inch industrial computer touch screen, and is equipped with a multi-function remote control, which is simple and convenient to operate.
Technical parameters of Prefabricated Building Light Steel Frame Villa Keel Forming Machine
| No. | Item | Specification | |||
| 1 | Powered Decoiler | ||||
| Loading weight | 3tons | ||||
| Coil Inner Diameter | 508mm | ||||
| Power | 1.5kw | ||||
| 2 | Roll Forming Machine | ||||
| Dimension | 5Mx1Mx1.8M | ||||
| Weight | 3500KGS | ||||
| Material of Rollers | Material: GCr15 | ||||
| Processing Technic for Rollers | CNC machining, heat treatment HRC58-60,then processed by CNC lathe, plating finally | ||||
| Material of Shafts | 40Cr | ||||
| Processing Technic for Shafts | CNC machining, quenching and tempering HRC28-32,then processed by CNC lathe, plating and polishing finally | ||||
| Sheet Guiding Device | |||||
| Holes Punching Device | (dimpling with screw holes,service hole,web notch,lip notch, truss end chamfer, swage, crimp) | ||||
| 3 | Control System | ||||
| Main control system | One Lenovo laptop and a control box inside of based frames of the machine | ||||
| Producing software | Special designed to match with the designing software Vertex | ||||
| Leaser Printing Device | USA Matthews Leaser Printing Device for painting spray logo and installation indicating number | ||||
| Remote-control device | Wireless remote-controller controls machine to go forward or backward or stop | ||||
| Brands of main components | PLC(self-developed),Relay (Schneider), proximity switch(Schneider), Encoder(Omron), Servo Motor(Xinjie) | ||||
| 4 | Servo System and Hydraulic System | ||||
| Servo motor | 5.5kw, taking with precision planetary gear reducer | ||||
| Hydraulic Station | 7.5KW;Hydraulic oil injection 200 litre | ||||
| 5 | Run-out Table | ||||
| Length | 3M | ||||
