| Place of Origin: | Hebei China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO、BV |
| Model Number: | LM-gutter1 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 35 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 60set/Year |
| Cutting System:: | Automatic Hydyaulic Cutting | Roller Stations:: | 18 Steps |
|---|---|---|---|
| Suitable Material:: | Galvanized Steel, GI | Forming Speed:: | 10-15m/min |
| Hydraulic Power:: | 4KW 380V 50HZ 3-phase | Color:: | Client's Request |
| Rolling Thinckness:: | 0.4-0.5 Mm | Advantage: | High Efficent |
| Shaft Diameter(Solid):: | 75mm | Driving Motor:: | 15Kw |
| Highlight: | Metal Roof Gutter Roll Forming Machine,4KW Gutter Roll Forming Machine |
||
Best Price Metal Roof Gutter Roll Forming Machine
The main function of the sink produced by "the best price metal roof gutter roll forming machine" is to collect dew and drain water. Generally, a galvanized sheet with a high zinc layer is used, which requires high corrosion resistance.
The gutters produced by the "best price metal roof gutter roll forming machine" are widely used in multi-span greenhouses, smart greenhouses, modern villas and multi-storey buildings.
The "best price metal roof gutter roll forming machine" can use color steel plate or aluminum plate to make gutter board. The formed plate is rolled and sealed, and then bent and necked by special equipment. It has good weather resistance, simple design, simple installation, safe and durable, noble and elegant.
The gutter plate produced by the "best price metal roof gutter roll forming machine" can be sprayed with rich colors according to the user's personal needs, and its metal texture and beautiful shape can bring a strong expression to the building.
Main parameters of Best Price Metal Roof Gutter Roll Forming Machine
| Model number | Best price metal roof gutter roll forming machine |
| Rolled material | 0.3-1.5mm thickness, aluminum sheet, galvanized sheet, colored steel sheet |
| and various steel plates | |
| Effective width | as customer's require |
| Feeding width | as customer's require |
| Forming steps | 9-18 stations |
| Roller | 45# forged steel, hard chrome plating within 0.05mm |
| Diameter of shaft | 70mm |
| Main motor power | 4 kw |
| Pump power | 3 kw |
| Sprocket chain | 1 inch |
| Drive type | by chain |
| Cutting Blade | Cr12, heat treatment 60-62°C |
| Frequency Converter | It has the advantage of slowing down before cutting, to ensure the length accuracy (±1mm, |
| far better than industrial standard ±3mm). | |
| component | 1 set of manual decoiler,1 set of main roll forming machine,1 set of computer control cabinet, |
| 1 set of hydraulic System,1 set of cutting mechanism,1 set of counter,1 set of output table | |
| Payment terms | cash,T/T,L/C. |
