| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-RSD14 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 30 work days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 450set/Year |
| Productivity: | Shutter As The Drawing | After-sales Service Provided: | Online Support, Free Spare Parts, Field Installation, Commissioning |
|---|---|---|---|
| Material Specification: | Aluminum, Galvalume, Galvanized And Pre-painted Galvanized Steel. | Number Of Forming Groups: | 12 Composition Molds, 3 Sets Of Straightening Wheels |
| Equipment Operation: | Automatically Plc | Thickness: | 0.5 Mm To 1.0mm |
| Hydraulic Motor Power(KW): | 5.5 | Certification: | CE、BV、ISO |
| Dimension(L*W*H): | Length 4500mm* Width 600mm* Height 800mm | Forming Roller Station: | 12 Stations |
| Highlight: | European Style Rolling Shutter Machine,12 Stands Rolling Shutter Machine,Length 4500mm Rolling Shutter Machine |
||
Custom 125 European Style Roller Shutter Forming Machine
Features of customized 125 European style roller shutter forming machine
1. customized 125 European style roller shutter forming machine has the characteristics of low energy consumption.
2. The high efficiency characteristics of customized 125 European style roller shutter forming machine0
3. customized 125 European style roller shutter forming machine can reduce loss cost for you.
4. customized 125 European style roller shutter forming machine can customize the speed and speed to meet your production needs.
Technical Parameters Of Custom 125 European Style Roller Shutter Forming Machine
| Productivity | shutter as the drawing |
| Material specification | Aluminum, galvalume, galvanized and pre-painted galvanized steel. |
| Thickness | 0.5 mm to 1.0mm. |
| Main motor power | 4.5 kw. |
| Hydraulic station power | 3 kw. |
| Feeding width | Depends on the model of profile. |
| Yield stress | 235Mpa(33KSI) ~ 350Mpa |
| Roll forming Speed | 12-15 m/minute. |
| Cutting Tolerance | +/-2.5mm(length≤5000mm); +/-3.0mm(5000mm<length≤10000mm) |
| Manual Uncoiler | Max. Capacity: 3000kgs |
| Coil inner diameter | 508mm/610mm. |
| Voltage | 380v/50hz/3 phase |
| Numbers of stands | 12 stands/stations/pairs for each roll forming system |
