| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-RSD17 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 30 work days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 450set/Year |
| Productivity: | Shutter As The Drawing | Main Motor Power: | 220V 60HZ 1PHASE 3KW |
|---|---|---|---|
| Production Speed: | Approximate 15-25 M/min | Number Of Forming Steps: | 14 Steps |
| Equipment Operation: | Automatically Plc | Thickness: | 0.8-1.2 Mm |
| Hydraulic Motor Power(KW): | 5.5 | Certification: | CE、BV、ISO |
| Dimension: | 4.2M(L)*0.8M(W)*1.2M(H) | Weight: | About 2.2Ton |
| Highlight: | 14 steps Rolling Shutter Machine,Gates Rolling Shutter Machine |
||
145 Stainless Steel Fireproof Rolling Shutter Door Roll Forming Machine
145 stainless steel fireproof rolling shutter door roll forming machine has a wide range of applications.
145 stainless steel fireproof rolling shutter door roll forming machine is suitable for producing stainless steel rolling gates, Austrian rolling gates, color steel rolling gates, galvanized rolling gates, single-layer stainless steel rolling shutters, double-layer stainless steel rolling shutters, wind-proof rolling shutters, And fire-proof rolling shutters, and muffler rolling shutters, etc.
145 stainless steel fireproof rolling shutter door roll forming machine introduces professional roll design software to assist computer design, with high product accuracy.
Technical Parameters Of 145 Stainless Steel Fireproof Rolling Shutter Door Roll Forming Machine
| 1 | Dimension | 4.2M(L)*0.8M(W)*1.2M(H) | |
| 2 | Weight | About 2.2Ton | |
| 3 | Main motor power | 220V 60HZ 1PHASE 3KW | |
| 4 | Hydraulic Pump Stations power | 220V 60HZ 1PHASE 3KW | |
| 5 | Structure of decoiler | 80mm*80mm square pipe welding | |
| 6 | Main shaft | ￠50mm.carbon steel through finish machining formed,Solid shaft | |
| 7 | Mid plate thickness | 18MM | |
| 8 | Drive Method | By gear | |
| 9 | Roller | 45# steel through striking,coarse machining by | |
| common lathe,finish machining by CNC lathe | |||
| frequency quenching,polishing and plating hard chrme on surface | |||
| 10 | Forming Stations | 12stations | |
| 11 | Formed Length and Cutting length | Controled by Computer | |
| 12 | Cutting Method | Automatic Hydraulic Cutting.Cutter Blade adopt Cr12 steel(coarse grinding | |
| ,heat treatment,accurate grinding,liner cutting)blade thickness:20MM | |||
| 13 | Wokring Speed | 10-12M/MIN | |
| 14 | Roll Thickness Material | 0.7MM | |
| 15 | Reducer | 3# Cycloidal planetary Reducer. | |
| 16 | Automatic Control System | upright control cabinet, adopt Delta PLC, transducer, Chint, DELIXI and other control elements | |
