| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-RSD24 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 30 work days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 450set/Year |
| Tile Type: | Colored Glaze Steel | Voltage: | 380v |
|---|---|---|---|
| Production Capacity: | 8-15m/min | Warranty: | 2 Years |
| Product Name: | 145 Thermal Insulation Roller Shutter Forming Machine | Thickness: | 0.3-1.2 Mm |
| Machine Weigh: | 4T | Certification: | CE、BV、ISO |
| Feeding Width: | 1220mm, 915mm, 900mm, 1200mm, 1000mm, 1250mm, Other | Dimension(L*W*H): | 6m*1.2m*1.4m |
| Highlight: | Glaze Steel Roller Shutter Forming Machine,Thermal Insulation Roller Shutter Forming Machine,Glaze Steel shutter roll forming machine |
||
145 Thermal Insulation Roller Shutter Forming Machine
Advantages of 145 thermal insulation roller shutter forming machine:
1.145 High quality hermal insulation roller shutter forming machine: We have a team of professional designers and experienced engineers. The raw materials and accessories we use are very good.
2.145 High-quality service of hermal insulation roller shutter forming machine: We provide technical support for the entire life cycle of the machine.
3.145 Warranty period of hermal insulation roller shutter forming machine: within two years from the date of completion of commissioning. The guarantee covers all electrical, mechanical and hydraulic parts except for wearing parts.
4.145 hermal insulation roller shutter forming machine is easy to operate: all machines are controlled by a PLC computer control system.
The 5.145 hermal insulation roller shutter forming machine has beautiful appearance: it can protect the machine from rust, and the paint color can be customized
Reasonable price of 6.hermal insulation roller shutter forming machine: We provide the best price in the industry.
Technical parameters of 145 Thermal Insulation Roller Shutter Forming Machine
| 145 thermal insulation roller shutter forming machine | |||
| Raw material | Material | PPGI/PPGL | |
| Coil width | 182mm | ||
| Coil thickness | 0.3-0.8mm | ||
| Forming Machine | Steps | 10/13rows according to sheet sizes | |
| Mid-plate | 14mm | ||
| Frame | Steel weld | ||
| Motor | Machine | 4.0KW | |
| Pump | 4.0KW | ||
| Computer | PLC | Taida | |
| Invertor | Sanjing | ||
| Screen | 5.7inche, touchd | ||
| Language | 7 languages | ||
