| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-purlin32 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 30 work days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 450set/Year |
| Main Frame:: | 300H Steel | Production Capacity:: | 16-20m/min |
|---|---|---|---|
| Type:: | Steel Frame & Purlin Machine | Thickness Of Coil Sheet:: | 1-3mm |
| Warranty: | 2 Years | Certification: | CE、BV、ISO |
| Main Motor Power:: | 22kw | Cutting Blade Material:: | Cr12Mov |
| Diameter Of Shaft:: | 70 Mm | Controlling System:: | Famous PLC Computer Control |
| Highlight: | Thickness 3mm Z Purlin Forming Machine,GCR15 Roller Z Purlin Forming Machine,Z Purlin Forming Machine |
||
3mm Thickness Z Shaped Purlin Roll Forming Machine
Our professional engineers will select suitable materials and high-quality parameters for the "3mm thickness Z shaped purlin roll forming machine", so that the machine can run well and prolong its service life. We will try our best to deal with all the details.
Comparison of advantages of "3mm thickness Z shaped purlin roll forming machine"
1. Energy consumption: "3mm thickness Z shaped purlin roll forming machine" saves electricity and energy (saving 15 kWh per hour)
2. Reduce waste disposal: "3mm thickness Z shaped purlin roll forming machine" has less length waste (flying saw cuts about 5mm, loss after cutting; unlimited cuts about 8mm of waste can be treated as waste.)
3. Environment: "3mm thickness Z shaped purlin roll forming machine" stepless cutting, no noise pollution, no dust, safe and durable.
4. In terms of labor: "3mm thickness Z shaped purlin roll forming machine" does not need to change the mold, and can be cut at will, saving time and energy.
5. "3mm thickness Z shaped purlin roll forming machine" can be replaced more quickly, without keeping a large number of molds.
Technical parameters of 3mm Thickness Z Shaped Purlin Roll Forming Machine
| Types of Purlin machine | C purlin machine | Z purlin machine |
| Cutting Type | Mould cutting | Mould cutting |
| Fly saw cutting | Fly saw cutting | |
| Wuji cuting | Wuji cuting | |
| Roller stations | 13 | 13 |
| Step of leveling roller | 3 upper step , 4 lower step | 3 upper step , 4 lower step |
| Thickness | 2-3mm | 2-3mm |
| Shaft diameter | 80mm | 80mm |
| Shaft type | solid | solid |
| Roller mayerial | GCR15 ,Quenching | GCR15 ,Quenching |
| PLC | Delta | Delta |
| Computer screen | Touch screen | Touch screen |
| Main motor | 11KW | 11KW |
| Hydraulic motor | 5.5KW | 5.5KW |
| Board thickness | 20mm | 20mm |
| Chain size | 2 inch | 2 inch |
