| Place of Origin: | Hebei China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO、BV |
| Model Number: | LM-gutter9 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 35 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 60set/Year |
| Operation:: | Touch Screen And Button | Roll Stations:: | 13 Rows |
|---|---|---|---|
| Suitable Material:: | PPGI | Production Capacity:: | 8-12m/min |
| Main Frame:: | H450 | Dimension(L*W*H):: | 4000*1000*1000mm |
| Rolling Thinckness:: | 0.3-1mm | Feeding Width:: | 310mm |
| Diameter Of Shafts:: | 60-80mm | Warranty:: | 2 Years |
| Highlight: | 7.8x0.8x1.2m Downspout Roll Forming Machine,H450 Frame Metal Gutter Machine,7.8x0.8x1.2m Metal Gutter Machine |
||
Metal Gutter Shaping Machine Downspouts Cold Roll Forming Machine
The machine tool processed the "Metal Gutter Shaping Machine Downspouts cold roll forming Machine". The blade has good toughness, abrasion resistance, sharpness, fast cutting and cutting board thorn effect, which is convenient for construction and installation.
"Metal Gutter Shaping Machine Downspouts cold roll forming Machine" is fully automatic computer controlled. Workers only need to input the number of meters of paper in the computer controller, and they can input multiple sets of data at the same time. One-key start, the machine will automatically generate. After reaching the set number of meters, the system controls automatic cutting.
The cutting part of "Metal Gutter Shaping Machine Downspouts cold roll forming Machine" is neat, with accurate production measurement and small errors.
The rollers of "Metal Gutter Shaping Machine Downspouts cold roll forming Machine" are processed by Cr12 precision turning, precision grinding, plating hardening and other machine tools, which are not easy to deform after long-term use. The rolled sheet has a beautiful appearance.
"Metal Gutter Shaping Machine Downspouts cold roll forming Machine" has experienced more than 20 years of ups and downs in China. The quality and performance of the equipment have been greatly improved, and the technology and capabilities have been greatly improved.
Main parameters of Full Automatic Downspout And Gutter Roll Forming Machine
| No. | rain water aluminum ogee K gutter cold roll forming machinery | |
| 1 | Suitable to process | Color alu-zinc steel coil |
| 2 | Roller | 16-18Rows |
| 3 | Dimensions | 7.8*0.8*1.2m |
| 4 | Motor Power | 5.5Kw |
| 5 | Pump Station Motor | 4Kw.Lichao Brand |
| 6 | Thickness of the plate | 0.3-0.8mm |
| 7 | Productivity | 3-5m/min |
| 8 | Material of the cutting blade | Cr12,Quenched treatment 58℃-60℃ |
| 9 | Diameter of the roller | Φ60mm |
| 10 | Weight | About 3600kgs |
| 11 | Main structure of the machine | 350H beams |
| 12 | Processing precision | Within 1.0mm |
| 13 | Side panel of machine | 16mm |
| 14 | Chain Wheel and Cycle Chain | 1 Inch |
| 15 | Voltage | 380V 50Hz 3phases or as customer's need |
| 16 | Control system | PLC control (Delta) |
| 17 | Frequency system | Delta |
| 18 | Drive mode | Motor driver |
| 19 | Touch screen | Delta |
| 20 | Rolling materials | 45# forging steel with chromium plate |
| 21 | Length Tolerance | ±2mm |
