| Place of Origin: | Hebei China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO、BV |
| Model Number: | LM-gutter 6 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 35 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 60set/Year |
| Applicable Industries:: | Hotels, Garment Shops, Building Material Shops, Farms, Restaurant, Home Use, Construction Works , Energy & Mining, Food & Beverage Shops | Roller Stations:: | 18 Steps |
|---|---|---|---|
| Key Selling Points:: | Long Service Life | Vertical Board:: | 18mm |
| After Warranty Service:: | Field Maintenance And Repair Service, Online Support, No Service, Video Technical Support | Forming Speed:: | 8-10m / Min |
| Voltage:: | 380V | Advantage: | High Efficent |
| Shaft Diameter(Solid):: | 75mm | Warranty:: | 2 Years |
| Highlight: | metal gutter forming machine,75mm shaft gutter forming machine,5.5kw gutter forming machine |
||
The metal gutter forming machine is the most popular forming machine. It is made into rain gutter panels of different shapes and is widely used in various industrial plants, buildings, factories, warehouses, supermarkets, hotels, exhibition halls, shopping centers, etc.
We adopt export standard technical solutions to make the metal downspout forming machine strong and stable.
The metal gutter forming machine adopts a gear box as the transmission method of the machine, which makes the metal gutter forming machine more powerful in order to deal with different thicknesses of raw materials, and also improves the efficiency of the machine.
The production speed of the metal gutter forming machine can be adjusted freely within 40m/min. The PLC with touch screen operation makes the machine easy to use.
At the same time, we can also provide you with safety guards, hydraulic decoilers, automatic stackers, etc. that are easy for you to operate. It can help you save labor, save costs, and ensure that your metal gutter forming machine is safer. Most importantly, it can improve your work efficiency.
Main parameters of Color optional, house decoration, simple operation, metal gutter forming machine
| Feeding form | Manual tightening, passive feeding |
| Feeding rack load | 5T |
| frame | 350H section steel welding |
| Forming machine guide feed frame | Side-skate peak distance |
| Forming machine form | Wall plate chain drive |
| Chain | 1 inch single row |
| Forming machine motor power | 5.5KW |
| Forming speed | 8-10m / min |
| Roll material | 45 # steel forged parts |
| Hydraulic station motor | 4kw |
| Hydraulic station oil pump | Gear pump |
| Cut off method | Hydraulic shear |
| Forming scissors material | Cr12 |
| Rolling thickness | 0.3-0.8MM |
| Computer control | PLC |
| drive | Servo motor drive |
