| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-Ladder3 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 40 work days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 450set/Year |
| Type:: | Tile Forming Machine | Voltage:: | 380V 50Hz 3phases |
|---|---|---|---|
| Applicable Industries:: | Manufacturing Plant | Dimension(L*W*H):: | 5500mm*1500mm*1200mm |
| Marketing Type:: | New Product 2020 | Certification: | CE、BV、ISO |
| Weight:: | 8T | Pump Station:: | 5.5kw |
| Hickness:: | 0.5-1.5mm | ||
| Highlight: | 0.5mm small roll forming machine,5.5kw small roll forming machine,fender molding small roll forming machine |
||
Mudguard Forming Machine is an equipment used to produce automobile mudguards
The fender forming machine consists of two modules: sheet forming and arching. First, the sheet forming module controls the uncoiling device, the feeding device, the forming host, and the shearing device through the PLC programming system to complete the sheet production. The arching module completes the arc Rolling to complete the production of automobile fenders.
Why do we divide the fender forming machine into two modules: sheet forming and arching.
1. Realize that the fender molding machine can not only produce automobile fenders but also veneers, so as to help you open up the market.
2. The integrated fender forming machine needs to keep the plate forming speed consistent with the arching forming speed, so that the production of automobile fenders can be completed. Such production will slow down the production speed of the fender forming machine However, we use the method of separating the plate forming module of the fender forming machine and the arching module of the fender forming machine, so that the plate forming module in the front section of the fender forming machine can be quickly produced, and then the fender forming machine The arching module at the end can be produced simultaneously, so as to achieve the purpose of improving work efficiency.
Technical parameters ofEasy-to-install Ladder Plate Roll Forming Machine
| Roller Material | Cr15 Steel,after rough turning then NC Lathe |
| Shaft diameter | 50mm |
| Shaft material | 45# steel with forging treatment |
| Motor Power | Hydraulic 5 5KW |
| Reducer Type | 250# |
| Production Speed | 30m/min(include forming/utting) |
| Transmission | Gear and Sprocket |
| Cutting Device | Servo tracking cutting |
| Cutting Motor | 5.5KW |
| Cutting Mold | Cr15MoV |
