| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-Carriage 10.29 3 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 35 work days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 450set/Year |
| Voltage: | 380v 3ph 50hz | Warranty: | 1.5 Years |
|---|---|---|---|
| Production Capacity: | 8-15m/min | Place Of Origin: | Hebei, China |
| Dimension(L*W*H): | 7800*1500*1200mm | Certification: | CE、BV、ISO |
| Rolling Thinckness: | 0.3-1.0mm | Weight: | 6.8T |
| PLC Control: | Delta | ||
| Highlight: | touch control steel roll former,plc steel roll former,car panel rollformers machine |
||
Touch PLC control custom car panel forming machine15m/min
The automobile panel forming machine is an equipment used to produce automobile panels. The products produced by the automobile panel forming machine have a wide range of uses, such as the side panels of containers and the side panels of trucks. Due to their corrosion resistance and strong pressure-bearing capacity , Installation is fast, and it is well received by people.
Technical parameters of Touch PLC control custom car panel forming machine15m/min
|
1
|
Suitable to process
|
Color steel plate
|
|
|
2
|
Width of the plate
|
1220mm
|
|
|
3
|
Rollers
|
14-18rows
|
|
|
4
|
Dimensions
|
7800*1500*1200mm
|
|
|
5
|
Power
|
7.5+4kw
|
|
|
6
|
Thickness of the plate
|
0.3-1.0mm
|
|
|
7
|
Productivity
|
8-15m/min
|
|
|
8
|
Diameter of the roller
|
Φ70mm
|
|
|
9
|
Weight
|
About 6.8 T
|
|
|
10
|
Voltage
|
380V 50Hz 3phases
|
|
|
11
|
Rolling material
|
Carbon Steel 45#
|
|
|
12
|
Material of the cutting plate
|
Cr12
|
|
|
13
|
Processing precision
|
Within 1.00mm
|
|
|
14
|
Control system
|
PLC control
|
|
|
15
|
Side panel of machine
|
14mm
|
|
|
16
|
Main structure of the machine
|
300 H steel
|
|
Process technology of automobile panel forming machine
Placement of raw materials--decoiling by uncoiling device---straightening and feeding---continuous cold-rolling forming---cutting to length---finished product receiving
Configuration of automobile panel forming machine
1. Automotive panel forming electrical control device: All Delta electrical control cabinet touch-type PLC display screens are used. The electrical control cabinet design is highly complex and can be easily manipulated by adults.
2. Hydraulic device of automobile panel forming machine: We use a 50L dual-motor hydraulic pump station to fully meet the pressure demand of automobile panel forming machine. At the same time, we also use steel multi-layer filter element to ensure the smooth flow of hydraulic oil, thereby helping Your fast production
3. Roller kun of automobile panel forming machine: We use Gr12 roller kun that has undergone rough turning, fine turning, heat treatment and other processes to ensure that the roller kun has high hardness and good toughness, which can help you in long-term production
4. The feeding device of the automobile panel forming machine: We are equipped with a four-point adjusting feeding device for this equipment, which can help you adjust the feeding position more quickly to ensure the accurate entry of raw materials, thereby helping you to produce products with precise dimensions.
After-sales of automobile panel forming machine
The accessories installed on our automobile panel forming machine are all international brands, which can be bought at any hardware store. At the same time, we will also provide you with 24-hour manual customers to solve all your questions about the automobile panel forming machine. At the same time, you are receiving the equipment Later, we will also provide you with operating videos and a list of accessories to help you operate the equipment quickly and skillfully
