| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-carr10 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 30 work days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 450set/Year |
| Type:: | Tile Forming Machine | Tile Type:: | Colored Steel |
|---|---|---|---|
| Production Capacity:: | 25M/min | Rolling Thinckness:: | 0.3-0.8mm |
| Warranty: | 2 Years | Certification: | CE、BV、ISO |
| Voltage: | 380V/220V/ 110V | Dimension(L*W*H):: | 5600*1500*1500mm |
| Cutting Blade Material:: | Cr 12 High Grade Steel | Weight:: | 1200kg |
| Highlight: | PLC Carriage Board Roll Forming Machine,380V Carriage Board Roll Forming Machine,6 Ton Carriage Board Roll Forming Machine |
||
Competitively Priced Automotive Carrier Board Roll Forming Machine
The components of "Competitively priced automotive carrier board roll forming machine":
The roll forming system consists of a frame, transmission parts and cold-formed rolls.
The "Competitively priced automotive carrier board roll forming machine" is divided into precision grinding wheel rotary forming, which has good forming effect, reduces the friction between the grinding wheel and the raw material, and is convenient and quick to debug.
The workflow of "Competitively priced automotive carrier board roll forming machine":
Uncoiling guided feeding roll forming-cutting into finished products
Manually fix the workpiece, manually roll it up, then enter the PLC operation page, press the "start" button, and then automatically enter the plate making start according to the set program, and cut it off after reaching the set size,"Competitively priced automotive carrier board roll forming machine" will automatically press the plate to complete.
Feeding guide platform of "Competitively priced automotive carrier board roll forming machine":
The left and right guides are located at the paper inlet of the main unit. When working, the two sides of the raw material board enter the host through the left and right guide rails to keep the raw material board and the roll forming system in the correct position. The guide position can be adjusted by a manual screw mechanism, and the left and right sides can be adjusted separately.
Cutting system of"Competitively priced automotive carrier board roll forming machine":
The cutting system consists of a cutting frame, a cutting die, a guide device and a cutting cylinder. The tool material is quenched molybdenum steel.
Technical parameters of Competitively Priced Automotive Carrier Board Roll Forming Machine
| Name | Competitively priced automotive Carrier Board roll Forming Machine |
| Appearance Size | 5600*2600*1600mm |
| Weight | 2-6Ton |
| Roller Material | High grade 45H forged steel |
| Blade Material | Cr12 With ppolished,heated and quenched HRC60-62℃ |
| Chrome Coating | Coated with 0.05 mm hard chrom |
| Control System | PLC control Siemens Brand |
| Main Motor Power | 5.5kw Siemens Brand |
| Hydraulic Power | 3-7.5kw |
| Roller Station | 13-18Rollers |
| Chain Material | High grede 45H steel |
| Forming Speed | 15-23m/min |
| Thickness | 0.2-0.8mm |
| Cutting | Hydraulic cutting |
| Rack Material | Complete welded structure of A3 steel plate |
| Frame Material | Welded with 350H steel |
| Machine forming type | Sigle station with chain transmisson |
| Viltage | 380V50H3Pha |
