| Place of Origin: | China |
|---|---|
| Brand Name: | LIMING |
| Certification: | CE、ISO |
| Model Number: | LM-Carriage 1 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Nude、Anti-dust film, Anti-rust cloth |
| Delivery Time: | 35 work days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 450set/Year |
| Type:: | Tile Forming Machine | Raw Material:: | Galvanized Sheet |
|---|---|---|---|
| Applicable Industries:: | Building Material Shops, Construction Works | Rolling Thinckness:: | 0.3-0.8mm |
| Warranty: | 2 Years | Certification: | CE、BV、ISO |
| Voltage: | 380v 3ph 50hz | Dimension(L*W*H):: | 7.5*1.5*1.5m |
| Utter Material:: | Cr.12 | Weight:: | 6.5 Ton |
| Highlight: | 0.3mm plate roll forming,BV plate roll forming,380v plate roll forming |
||
High-Speed Cutting Automobile Side Plate Roll Forming Machine
The automobile side plate roll forming machine adopts a gear box transmission method, which makes the machine more powerful, can cope with thicker versions, and helps you improve production efficiency.
The automobile side plate roll forming machine is also equipped with a servo shearing device for you to synchronize the shearing device with the product, so that the machine saves the time of shutting down and cutting, and it also helps you to speed up the production speed.
The whole machine of the automobile side plate roll forming machine is controlled by PLC electronic control. It can be automatically produced by filling in the parameters and speed, which not only helps you save the cost of employment but also saves the production process.
The product produced by the automobile side plate roll forming machine is accurate in size, and the product has no scratches or burrs and can be directly used for sales or project use.
Technical parameters of High-Speed Cutting Automobile Side Plate Roll Forming Machine
| Coil Type | PPGL,Galvanized steel |
| Width | 1250mm |
| Thickness range | 1-2mm |
| Yield stress(mm) | Q235 |
| Forming speed | 15m/min |
| Main Frame | 350H beam |
| Chains | 1inch chain drive |
| Voltage | (380V 50HZ),or according client require |
| Main Motor power | 5.5kw |
| Cutter power | 5.5kw |
| Forming stations | 16 row axis diameter 70 axis |
| Sidewall thickness | 14mm |
| Type of cutting | Roll formed and length-set cutting |
